Thieme 1000

Semi-automatic, shuttle table screen printing machine for flexible and rigid substrates

Be the first to review this product

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Semi-automatic, shuttle table screen printing machine for flexible and rigid substrates.

Better print quality through absolutely steady and viration-free screen, even when printing large sizes
Increased repeatability as the screen frame remains positively locked into position
Enhancements to "dry-in" problems due to low print head movement resulting in less air swirl
Faster print speed with enhanced dwell settings and print head programming
Equipped with the patented THIEME squeegee unit and other various features which considerably reduce set-up times

Specifics

User friendly operation
SPS control system with touch-screen display
Proven THIEME squeegee Unit
Print stroke infinitely adjustable via analog switches
Pneumatic frame clamping
Economical start in the Thieme technology

SKU: Thieme 1000

Semi-automatic, shuttle table screen printing machine for flexible and rigid substrates.

Better print quality through absolutely steady and viration-free screen, even when printing large sizes
Increased repeatability as the screen frame remains positively locked into position
Enhancements to "dry-in" problems due to low print head movement resulting in less air swirl
Faster print speed with enhanced dwell settings and print head programming
Equipped with the patented THIEME squeegee unit and other various features which considerably reduce set-up times

Specifics

User friendly operation
SPS control system with touch-screen display
Proven THIEME squeegee Unit
Print stroke infinitely adjustable via analog switches
Pneumatic frame clamping
Economical start in the Thieme technology

Signalization
Signage
Textile
Special applications
Decoration
POP displays

This product is sold out

Products specifications

Attribute name	Attribute value
Model	Thieme 1000
Media handling	Semi-automatic
Print format	550 x 750mm (Thieme 1010) \| 750 x 1050mm (Thieme 1020) \| 1000 x 1400mm (Thieme 1030) \| 1200 x 1600mm (Thieme 1040) \| 1400 x 1800mm (Thieme 1050) \| 1550 x 2100mm (Thieme 1060)
Sheet format	580 x 780mm (Thieme 1010) \| 780 x 1080mm (Thieme 1020) \| 1030 x 1420mm (Thieme 1030) \| 1230 x 1670mm (Thieme 1040) \| 1430 x 1870mm (Thieme 1050) \| 1580 x 2170mm (Thieme 1060)
Σχήμα τελάρου	1000 x 1100mm (Thieme 1010) \| 1200 x 1400mm (Thieme 1020) \| 1450 x 1750mm (Thieme 1030) \| 1700 x 2000mm (Thieme 1040) \| 1900 x 2200mm (Thieme 1050) \| 2050 x 2500mm (Thieme 1060)
Speed	Made to order
Squeegee speed	0,2-1,4 m/sec
Media thickness	Up to 50mm
Dimensions (W x D x H)	2225(M) x 1732(Π) (Thieme 1010) \| 2625(M) x 2032(Π) (Thieme 1020) \| 3125(M) x 2382(Π) (Thieme 1030) \| 3575(M) x 2632(Π) (Thieme 1040) \| 3975(M) x 2832(Π) (Thieme 1050) \| 4275(M) x 3132(Π) (Thieme 1060)
Weight	1200 kg (Thieme 1010) \| 1300 kg (Thieme 1020) \| 1450 kg (Thieme 1030) \| 1550 kg (Thieme 1040) \| 1560 kg (Thieme 1050) \| 1750 kg (Thieme 1060) \|
Power requirements	400/230 V
Power consumption	4/400, 7/230 (A/V)
Operating environment	Temperature -20 to +50°C. Relative humidity 30 to 75%. Air pressure 700 to 1060 hPa
Optional equipment	Optic feeding controls, anti-drip unit, vision system (2 independent camera systems for automatic screen positioning and substrate alignment), automatic screen moistening, print surface cleaning systems, screen stretch compensation
