G-Dry 571

Modular drying cabinet

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

The dryer is available in a wide range of size combinations
Screen height (SH): 1600 - 2400 mm in increments of 200 mm
Screen length (SL): 1000 - 3000 mm in increments of 250 mm
Thanks to the modular conception, it can be adapted to many different situations
All the pertinent components are accessible from the inside, which means that several dryer units can be lined up seamlessly.
Flexible interior equipment: the customer can choose among various screen holding devices and screen carriages
One-sided double door with transparent acrylic glass panel (A1) As an optional also double-sided for passing the screens (A2)
Drying of wet or coated screens
Infinitely variable control of the heating temperature up to 45° C
Heating system with air circulation for an even temperature distribution
Rugged construction made of aluminum and stainless steel
Compact construction
Dismountable for transport and setting-up

SKU: G-Dry 571

The dryer is available in a wide range of size combinations
Screen height (SH): 1600 - 2400 mm in increments of 200 mm
Screen length (SL): 1000 - 3000 mm in increments of 250 mm
Thanks to the modular conception, it can be adapted to many different situations
All the pertinent components are accessible from the inside, which means that several dryer units can be lined up seamlessly.
Flexible interior equipment: the customer can choose among various screen holding devices and screen carriages
One-sided double door with transparent acrylic glass panel (A1) As an optional also double-sided for passing the screens (A2)
Drying of wet or coated screens
Infinitely variable control of the heating temperature up to 45° C
Heating system with air circulation for an even temperature distribution
Rugged construction made of aluminum and stainless steel
Compact construction
Dismountable for transport and setting-up

There is no further information

Products specifications

Attribute name	Attribute value
Model	G-Dry 571
Screen format	SL screen length mm 1000-3000 / SH screen height mm 1600-2400 / Frame profile thickness mm 20-55
Dimensions (W x D x H)	Width mm 1600 / Depth mm SL+240 / Height mm SH+590
Power requirements	Voltage V 3x400+N+PE / 3x220+PE / Frequency Hz 50/60
