G-Wash 130

In-Line automatic frame washer

€0,00

Isporučiti do

Način isporuke

Ime

Procenjena isporuka

Cena

Nema mogućnosti isporuke

Washing, de-emulsion, developing functions
Maximum frame dimensions 1 x 1.2m
Maximum flexibility thanks to the modular construction of the system
Possibility of upgrading existing installations
Possibility of choosing the direction of the workflow depending on the requirements
Innovative nozzle system
Closed water recycling circuit with filters
Possibility of adding a sloped filter and solvent evaporation system
Easy cleaning of tanks thanks to the structure of the system that offers easy accessibility
For new generation solvents, with a flash point >55°C, ATEX-compliant construction method
Possibility of adding a sloped filter and solvent evaporation system
Unit rinsing with clean water for initial wetting and final rinsing of the frames
Integrated hand wash basin for final inspection and touch-up of the frames
Integrated fan for water drainage and removal of residues on the gauze
High productivity
Special Grünig nozzles made of V2A stainless steel
Programming of all washing parameters via touch screen terminalικού με οθόνη αφής

ID: G-Wash 130

Washing, de-emulsion, developing functions
Maximum frame dimensions 1 x 1.2m
Maximum flexibility thanks to the modular construction of the system
Possibility of upgrading existing installations
Possibility of choosing the direction of the workflow depending on the requirements
Innovative nozzle system
Closed water recycling circuit with filters
Possibility of adding a sloped filter and solvent evaporation system
Easy cleaning of tanks thanks to the structure of the system that offers easy accessibility
For new generation solvents, with a flash point >55°C, ATEX-compliant construction method
Possibility of adding a sloped filter and solvent evaporation system
Unit rinsing with clean water for initial wetting and final rinsing of the frames
Integrated hand wash basin for final inspection and touch-up of the frames
Integrated fan for water drainage and removal of residues on the gauze
High productivity
Special Grünig nozzles made of V2A stainless steel
Programming of all washing parameters via touch screen terminalικού με οθόνη αφής

Нема више информација

Specifikacije proizvoda

Naziv atributa	vrednost atributa
Models	G-Wash 130 &G-Wash 135
Σχήμα τελάρου	Πλάτος τελάρου: 1250mm / Ύψος τελάρου: 1000 mm / Ύψος πλαισίου: 25-45mm
Frame profile thickness	20-300mm
Dimensions (W x D x H)	(G-Wash 130) Width: 5000-11500mm - Height: 1500mm - Depth: 2050mm / (G-Wash 135) Width: 7600mm - Height: 2050mm - Depth: 1500mm
Power requirements	3x400+N+PE / 3x220+PE, 50/60 Hz
